Understanding Content Projection in Angular

Content projection is a core Angular feature that makes components more flexible and reusable. It allows you to pass HTML content from a parent component into a child component, making your UI more dynamic.

Let's start with a hands-on example. First, create a component named my-cards and add it to app.component.html using its selector. Here's what that looks like:

Content Projection in Angular — figure 1

Now, let's put content projection to the test. In app.component.html, add the following code:

<app-my-cards>
    <span>
        This is some content in between the card selector!
    </span>
</app-my-cards>

When you view this in the browser, you'll notice the text between the selector—This is some content in between the card selector!—isn't displayed. Let's see why.

Content Projection in Angular — figure 2

The span element here is the content child—it's both the content and a child of the selector. Since Angular doesn't automatically render content children, we need a way to project them into the child component. This is where the ng-content placeholder comes in.

The ng-content directive acts as a hole in the child component's template where projected content gets inserted. Let's update MyCardsComponent's template to include it:

<ng-content></ng-content>

After adding ng-content, you'll see the content appears as expected:

Content Projection in Angular — figure 3

So what's happening here? The span content is being projected into the ng-content placeholder, which then renders it in the template.

But what if you need multiple placeholders? For instance, you might have content for a card header, body, and footer all within the same card. That's where the select attribute comes into play—it's a powerful tool for targeting specific content.

The select attribute can match a class, id, attribute, or an element. Let's see it in action. First, update app.component.html with the following:

<app-my-cards>
    <header>Card Header</header>
    <span id='card-sub-header'>Card Sub Header</span>
    <div class="card-body">
        This is a card Body!!!
    </div>
    <footer title="card-footer">
        Card Footer.
    </footer>
</app-my-cards>

Then, in my-cards.component.html, the template for MyCardsComponent, add this:

<ng-content select='header'></ng-content>
<ng-content select='#card-sub-header'></ng-content>
<ng-content select='.card-body'></ng-content>
<ng-content select='[title]'></ng-content>

Here's what the output looks like:

Content Projection in Angular — figure 4

In this example: 1. The first ng-content selector targets an element—the header tag. 2. The second selector matches an id, specifically card-sub-header. 3. The third selector matches a class, card-body. 4. The fourth selector matches an attribute, title.

Now, imagine a scenario where you can't use a header tag but need a div instead, as shown below—and you also can't modify the card component. What do you do?

<app-my-cards>
    <div >Card Header</div>
    <span id='card-sub-header'>Card Sub Header</span>
    <div class="card-body">
        This is a card Body!!!
    </div>
    <footer title="card-footer">
        Card Footer.
    </footer>
</app-my-cards>

That's where ngProjectAs saves the day!

With ngProjectAs, you can tell Angular to treat an element as if it matches a different selector. Add this code:

<app-my-cards>
    <div ngProjectAs='header'>Card Header</div>
    <span id='card-sub-header'>Card Sub Header</span>
    <div class="card-body">
        This is a card Body!!!
    </div>
    <footer title="card-footer">
        Card Footer.
    </footer>
</app-my-cards>

Notice the first line: a div tag with ngProjectAs='header'. Angular now treats this div as a header element for projection purposes, so the output remains correct.
