Multi-stage Docker Builds for Angular with Nginx

This guide demonstrates how a multi-stage Dockerfile can compile an Angular application and then package it inside an Nginx container.


The Dockerfile shown above is composed of two distinct phases:

  • Phase 1: Installing NPM dependencies and compiling the Angular project
  • Phase 2: Constructing the Docker image using the dist folder generated in the preceding phase

Phase 1: Dependency Installation and Angular Compilation

  • The project is built with the Node 16 alpine image, which also accepts a CONFIGURATION build argument. At build time, this value can be changed according to your target environment.
docker build --build-arg CONFIGURATION=dev .
Enter fullscreen mode Exit fullscreen mode

Additionally, you have the flexibility to define any number of other arguments as needed.

  • Set /app as the working directory. All source code and project files will be transferred into the /app folder within the Node container.
WORKDIR /app
Enter fullscreen mode Exit fullscreen mode
  • Copy the package.json file into the /app directory. This step allows Docker to preserve and reuse the node_modules cache. Subsequent builds will rely on this cached layer as long as package.json remains unchanged, avoiding a full dependency reinstall.
COPY package.json .
Enter fullscreen mode Exit fullscreen mode
  • Run the npm install command to fetch dependencies, passing the —-legacy-peer-deps flag to avoid compilation failures on NPM versions 7 and above.
RUN npm install --legacy-peer-deps
Enter fullscreen mode Exit fullscreen mode
  • Afterwards, transfer the application source code and execute npm run build to generate the production build.
COPY . .
RUN npm run build --  --output-path=dist --configuration=$CONFIGURATION --output-hashing=all
Enter fullscreen mode Exit fullscreen mode
  • The compiled application files will reside in the /app/dist directory inside the Node container.

Phase 2: Constructing the Docker Image

  • The Nginx alpine stable image serves as the runtime environment for the Angular application in production.
  • Clear the pre-existing HTML files with the following command:
RUN rm -rf /usr/share/nginx/html/*
Enter fullscreen mode Exit fullscreen mode
  • Transfer the Nginx configuration file from the source tree to the /etc/nginx/nginx.conf location. If you lack a custom configuration, the sample provided below can be used.
  • Next, copy the dist folder from the build stage into the Nginx web root directory.
COPY — from=builder /app/dist /usr/share/nginx/html
Enter fullscreen mode Exit fullscreen mode
  • Finally, specify the Nginx start command in the Dockerfile. That completes the setup.

It's also possible to break Phase 1 into two independent stages: one dedicated solely to installing dependencies, and another focused on compiling the Angular application :)
