Angular 7's New Drag and Drop Feature in the CDK

Building Interactive Lists with the new Angular 7 Drag and Drop tool — figure 1

Angular is a TypeScript-based framework for crafting web, mobile, or desktop applications, boasting over 42,000 stars on GitHub. The framework is backed by Google's Angular Team along with numerous community members and organizations. Angular Version 7 hit the scene a few weeks ago, and it brought along a notable addition: the Drag and Drop tool within the Component Development Kit.

Understanding the Component Development Kit (CDK)

The Component Development Kit offers a collection of tools that implement standard behaviors and components with distinct interaction patterns, all while staying agnostic about template design. Think of it as an abstraction layer over the Angular Material Library that avoids Material-specific styling. This approach opens up more creative avenues when you're building your Angular components.

Introducing the Drag and Drop Tool

The Drag and Drop tool falls under the common behaviors provided by the component development kit. It ships with directives that bring high-quality drag-and-drop functionality to your components.

Using the @angular/cdk/drag-drop module, you can declaratively set up drag-and-drop interfaces with ease. It supports free dragging, sorting within a list, moving items between lists, animations, touch devices, custom drag handles, previews, and placeholders—plus horizontal lists and axis locking.

Getting Ready

Before diving into the Drag and Drop tool, there are four prerequisites to have in place in your Angular 7 workspace.

The newest Angular release (version 7)

// run the command in a terminal
ng version

An Angular 7 project set up

//cd to a preferred location
// run the command below
ng new dragdrop

Angular Material added to that project

ng add @angular/material

Import the Drag Drop module into the app module so it's accessible throughout the application, as shown here:

Building Interactive Lists with the new Angular 7 Drag and Drop tool — figure 2

Creating a List

Since drag and drop often works with lists, let's build a compact list of pop artists and then layer on the drag-and-drop capabilities.

Head to the app component file and add an array of artists like this:

// hardcode the array of artists below
import { Component } from '@angular/core';

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  styleUrls: ['./app.component.css']
})

export class AppComponent {
  artists = [
    'Artist I - Davido',
    'Artist II - Wizkid',
    'Artist III - Burna Boy',
    'Artist IV - Kiss Daniel',
    'Artist V - Mayorkun',
    'Artist VI - Mr. Eazi',
    'Artist VII - Tiwa Savage',
    'Artist VIII - Blaqbonez',
    'Artist IX - Banky W',
    'Artist X - Yemi Alade',
    'Artist XI - Perruzi',
    'Artist XII - Seyi Shay',
    'Artist XIII - Teni'
  ];


}

In the app component HTML file, swap out the boilerplate with an ngFor loop to display the list.

// replace the boilerplate code with this
<div  *ngFor="let artist of artists" >{{artist}}</div>

Add some styling to the app component CSS file as follows:

// add a pop class to the html file first
.pop{
    height: 50px;
    width: 40%;
    margin-left: 20px;
    border: 1px solid saddlebrown;
    display: flex;
    justify-content: center;
    align-items: center;

}

Now our pop artist list is styled and rendered in a way that makes items easy to see when dragged around.

Building Interactive Lists with the new Angular 7 Drag and Drop tool — figure 3

With the list in place, we'll explore the main features of the new drag and drop tool in the component development kit:

Basic Drag and Drop
Sorting
Moving Items between Lists
Animations

Getting Started with Drag and Drop

Simply adding the cdkDrag directive to a list item renderer makes that item draggable.

<div *ngFor=”let artist of artists” class=”pop” cdkDrag>{{artist}}</div>

Building Interactive Lists with the new Angular 7 Drag and Drop tool — figure 4

At this point, items can be dragged anywhere in the DOM. To restrict movement to the list area, wrap it inside a cdkDropList div.

<div cdkDropList>
<div *ngFor=”let artist of artists” class=”pop” cdkDrag>{{artist}}</div>
</div>

Implementing Sorting

Now that items can be moved around the DOM or within a list, we can take it up a notch by reordering items—essentially moving them up and down the list. This requires listening for the cdkDropListDropped event and using the moveItemInArray method to enable reordering.

Update the app.component.html file with this:

<div cdkDropList (cdkDropListDropped)=”drop($event)”>
<div *ngFor=”let artist of artists” class=”pop” cdkDrag>{{artist}}</div>
</div>

Update the app.component.ts file with this:

drop(event: CdkDragDrop<string[]>) {
moveItemInArray(this.artists, event.previousIndex, event.currentIndex);
}

The moveItemInArray method requires three arguments:

The array where the reordering happens
event.previousIndex—the original index of the dragged item
event.currentIndex—the new index where the item is dropped, enabling the swap

Building Interactive Lists with the new Angular 7 Drag and Drop tool — figure 5

Make sure to import CdkDragDrop and moveItemInArray from @angular/cdk/drag-drop

Transferring Items Between Lists

Now for the fun part: we've managed to reorder items within a list using drag and drop. Let's push it further and enable reordering across two separate lists. With the cdkDropList directive, you can link multiple cdkDropList elements (divs) together by wrapping them in a parent with a cdkDropListGroup attribute or by setting the cdkDropListConnectedTo property.

In app.component.html

<div style=”display: flex”>
<div cdkDropList [cdkDropListData]=”artists”
[cdkDropListConnectedTo]=”secondList” #firstList=”cdkDropList”
(cdkDropListDropped)=”drop($event)” style=”width: 30%”>
<div *ngFor=”let artist of artists” class=”pop” cdkDrag>{{artist}}</div>
</div>
<div cdkDropList [cdkDropListData]=”alteArtists”
[cdkDropListConnectedTo]=”firstList” #secondList=”cdkDropList”
(cdkDropListDropped)=”drop($event)” style=”width: 30%”>
<div *ngFor=”let artist of alteArtists” class=”pop” cdkDrag>{{artist}}</div>
</div>
</div>

What we did here:

Introduced a new droplist on lines 7–11 to render an additional list
Wrapped both droplist divs in a flex-styled container so they display separately
Set the droplist data for each list on lines 2 and 7
Defined which list each list connects to on lines 3 and 8
Added IDs to the drop lists so Angular recognizes them as distinct entities

In app.component.ts

alteArtists = [
‘Artist 1 — Odunsi’,
‘Artist 2 — Nonso’,
‘Artist 3 — Wavy the creator’,
‘Artist 4 — Dwin’,
‘Artist 5 — SDC’,
‘Artist 6 — Teni’
];
drop(event: CdkDragDrop<string[]>) {
if (event.previousContainer !== event.container) {
transferArrayItem(event.previousContainer.data,event.container.data,
event.previousIndex, event.currentIndex)
} else {
moveItemInArray(this.artists, event.previousIndex, event.currentIndex);
}
}

What we did here:

Created a new alteArtists array with its own data.
Added an if-else structure to adapt the moveItemInArray approach.
The if branch handles scenarios where an item is dragged into a different drop list
The else branch retains the previous logic for reordering within the same list

Building Interactive Lists with the new Angular 7 Drag and Drop tool — figure 6

Adding Animations

We can optionally enhance the drag-and-drop experience with transition styling. The module supports animations for sorting items within a list and for dropping items into a list. Here's a basic example:

In app.component.css:

/* Animate items as they’re being sorted. */
.cdk-drop-list-dragging .cdk-drag {
transition: transform 250ms cubic-bezier(0, 0, 0.2, 1);
}
/* Animate an item that has been dropped. */
.cdk-drag-animating {
transition: transform 300ms cubic-bezier(0, 0, 0.2, 1);
}

Building Interactive Lists with the new Angular 7 Drag and Drop tool — figure 7

It might not be buttery smooth just yet, but you'll notice the transition effects versus a version without them. If you've followed along, your final app component folder should look like this:

app.component.html

<div style="display: flex">
<div cdkDropList  [cdkDropListData]="artists"
[cdkDropListConnectedTo]="secondList" #firstList="cdkDropList"
(cdkDropListDropped)="drop($event)" style="width: 30%">
<div  *ngFor="let artist of artists" class="pop" cdkDrag>{{artist}}</div>
</div>
<div cdkDropList [cdkDropListData]="alteArtists"
[cdkDropListConnectedTo]="firstList" #secondList="cdkDropList"
 (cdkDropListDropped)="drop($event)" style="width: 30%">
<div  *ngFor="let artist of alteArtists" class="pop" cdkDrag>{{artist}}</div>
</div>
</div>

app.component.ts

import { Component } from '@angular/core';
import { CdkDragDrop, moveItemInArray, transferArrayItem } from '@angular/cdk/drag-drop'

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  styleUrls: ['./app.component.css']
})

export class AppComponent {
  artists = [
    'Artist I - Davido',
    'Artist II - Wizkid',
    'Artist III - Burna Boy',
    'Artist IV - Kiss Daniel',
    'Artist V - Mayorkun',
    'Artist VI - Mr. Eazi',
    'Artist VII - Tiwa Savage',
    'Artist VIII - Blaqbonez',
    'Artist IX - Banky W',
    'Artist X - Yemi Alade',
    'Artist XI - Perruzi',
    'Artist XII - Seyi Shay',
    'Artist XIII - Teni'
  ];

  alteArtists = [
    'Artist 1 - Odunsi',
    'Artist 2 - Nonso',
    'Artist 3 - Wavy the creator',
    'Artist 4 - Dwin',
    'Artist 5 - SDC',
    'Artist 6 - Teni'
  ];

  drop(event: CdkDragDrop<string[]>) {
    if (event.previousContainer !== event.container) {
      transferArrayItem(event.previousContainer.data,event.container.data,
        event.previousIndex, event.currentIndex)
    } else {
      moveItemInArray(this.artists, event.previousIndex, event.currentIndex);
    }
  }
}

app.component.css

.pop{
    height: 50px;
    margin-left: 20px;
    border: 1px solid saddlebrown;
    display: flex;
    justify-content: center;
    align-items: center;

}
.cdk-drop-list-dragging .cdk-drag {
    transition: transform 250ms cubic-bezier(0, 0, 0.2, 1);
  }

  .cdk-drag-animating {
    transition: transform 300ms cubic-bezier(0, 0, 0.2, 1);
  }

Wrapping Up

This tutorial walked through the new Angular 7 CDK drag and drop tool, showcasing practical uses and the UX possibilities it unlocks. For more details, check the CDK docs here. The source project is available on GitHub here if you want to fork and experiment. Share your drag and drop ideas in the comments, and happy coding!
